300ml Silicone Thermal Grease

  • 1
  • 2

Brand Name : BAI YUN

Model Number : SGH132

Certification : /

Place of Origin : Guangzhou, Chna

MOQ : 1000PCS

Price : Negotiation

Payment Terms : T/T, L/C

Supply Ability : 1000000PCS/month

Delivery Time : 7-14days

Packaging Details : 300ml

Color : white

Volume : 1kg

Storage : Under 27°C

Shelf life : 12 months

Appearance : White

Application : Power modules

Contact Now

SGH132 Thermal Conductive Grease 300ml Cartridge for LED or Power modules Application
SGH132 thermal conductive grease is a paste-like thermal interface material based on siloxane polymer and thermal conductive fillers. SGH132 can fill micro voids and reduce contact resistance. It is suitable for screen printing, automatic dispensing, brushing and other processes.

APPLICATIONS

  • LED assemblies
  • Communication equmipment or electronic device
  • Power module
  • Any interface that requires heat conduction or heat dissipation

DESCRIPTION

SGH132 thermal conductive grease is a paste-like thermal interface material based on siloxane polymer and thermal conductive fillers. SGH132 can fill micro voids and reduce contact resistance. It is suitable for screen printing, automatic dispensing, brushing and other processes.

KEY FEATURES

  • Good thermal conductivity with low oil bleed and low VOC
  • Achieves thin bond lines under low pressure
  • High stability and reliability
  • Solvent free and environmental friendly

TYPICAL PROPERTIES

Property Typical Value Test Method
Appearance(Color) White Visual
Specific Gravity(g/cm3) 2.15 GB/T 13477-2002
Thermal Conductivity(W/mK) ≥0.80 ISO22007-2-2015
Thermal Resistance(℃-cm2/W) ≤0.56 ASTM D5470@40psi
Oil Bleed(%) ≤0.01 120℃/24h
Volatile Content(%) ≤0.5 120℃/24h
Specifications: Typical property data values should not be used as specifications.

APPLICATION METHODS

  • Thickness and coating uniformity are the key attributes affecting the thermal performance of silicone grease. Appropriate construction methods should be used according to actual needs to obtain thin Bond Lines Thicknesses(BLTs)and uniform grease layer.
  • All surfaces should be thoroughly cleaned and/or degreased with solvents such as methyl ethyl ketone (MEK).
  • It is suitable for screen printing or automatic dispensing or syringe dispensing.
  • Adequate ventilation or air-supplied or self-contained breathing apparatus should be needed.

USABLE LIFE AND STORAGE

When stored at or below 27ºC(80ºF)in the original unopened containers, this product has a usable life of 12 months from the date of manufacture.

PACKAGING INFORMATION

SGH132 Thermal Conductive Grease is available in 10.1 fl. oz.(300 ml)plastic cartridges and 1kg plastic tub.

300ml Silicone Thermal Grease

HANDLING AND SAFETY

PRODUCT SAFETY INFORMATION REQUIRED FOR SAFE USE IS NOT INCLUDED IN THIS DOCUMENT. BEFORE HANDLING, READ PRODUCT AND MATERIAL SAFETY DATA SHEETS AND CONTAINER LABELS FOR SAFE USE, PHYSICAL AND HEALTH HAZARD INFORMATION. THE MATERIAL SAFETY DATA SHEET IS AVAILABLE FROM BAIYUN SALES APPLICATION ENGINEER, OR DISTRIBUTOR, OR BY CALLING BAIYUN CUSTOMER SERVICE.

The values in this document are not of all specifications and are subject to change without notice. As the actual situation is very different, it’s hard to guarantee the correctness and applicability of our products in some usage. Users should understand the product before using, and then decide the best way to use it.
